Components and circuits

Electronics clean down to the nanometre

Cleaning before wire bonding, wettability for soldering and adhesion for component encapsulation.

Assess my case in 48 h Discover our support services
The challenge

The surface challenge

At component scale, a thin layer of oxide or organic contamination is enough to compromise a wire bond, a die attach or an encapsulation. Wet methods are sometimes too aggressive or poorly compatible with fragile substrates.

Atmospheric plasma cleans and activates dry, in a targeted and gentle way. It prepares surfaces for the most sensitive assembly steps.

Plasma in action

What plasma changes

Cleaning before wire bonding

Remove oxides and contamination for reliable bonds.

Wettability for soldering

Improve solder spreading on difficult surfaces.

Encapsulation adhesion

Prepare surfaces for durable underfill or potting.

Treatment of sensitive substrates

A dry process compatible with fragile components.

Ink guiding and printing

Define wettable and non-wettable zones to precisely guide the deposition of conductive and functional inks in printed electronics.

Compatibility

Frequently treated materials

PCB / FR-4 Copper Gold Polyimide Ceramics Glass

This list is indicative. The vast majority of polymers, metals, glasses and composites can be treated with DBD plasma. The best way to confirm your case is to send us a description of your part and your objective.

A clean surface, a reliable bond.

48 hours to find out what plasma can do for your surfaces. No commitment, just clear answers from an expert.

I want my 48-hour assessment View our reactors

Response within 48 hours. No commitment. A technical discussion with an expert.
